Mărime: Cadru S4
Durata de livrare: 24-48 ore
Model: Unisex
Tip cadru: Full suspension
Material cadru: Aluminiu
Aplicație: Trail, Enduro
Diametru roată (inch): 29
Sistem de frânare: Disc-hidraulic
Transmisie: 1x12 viteze
Colecție: 2023
Culori: Rosu
Amortizor spate: X-Fusion 02 Pro RL, Rx Trail Tune, rebound adjust, lockout S1:190x42.5mm, S2-S6: 190x45mm
Angrenaj: SRAM SX Eagle, S2-S5: 170mm 30t
Anvelopă față: Butcher, GRID casing, GRIPTON® T7 compound, 29x2.3
Anvelopă spate: Purgatory, GRID casing, GRIPTON® T7 compound, 29x2.3
Butuc față: Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Butuc spate: Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
Cadru: Alloy chassis and rear-end, asymmetrical design, 29 Trail Geometry, horst pivot BB adjustment, threaded BB, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm of
Frâne: Tektro Gemini Comp, hydraulic disc, resin pad
Furcă: RockShox 35 Silver, Solo Air, 44mm offset, rebound adjust, TurnKey lockout, 15x110mm Boost™ Maxle® Lite thru-axle, 140mm of travel
Ghidon: Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
Jante: Double-wall alloy, 27mm internal width, 28h
Lanț: SRAM SX Eagle, 12-speed
Manetă schimbator: SRAM SX Eagle, trigger, 12-speed
Manete frână: Tektro Gemini
Manșoane: Specialized Trail Grips
Pedale: Nu sunt incluse
Pinioane: Sram PG-1210 Eagle, 11-50T
Pipă: Alloy Trail Stem, 35mm bar bore
Schimbător pinioane: Sram SX Eagle, 12-Speed
Șa: Body Geometry Bridge Saddle, steel rails
Tijă șa: TranzX dropper, 34.9mm, S1: 100mm, S2: 125mm, S3: 150mm. S4-S5: 170mm, S6- 200mm
Greutate: 16,2 kg (marime S4)
Size | S1 | S2 | S3 | S4 | S5 | S6 |
Crank Length | 165 | 170 | 170 | 170 | 170 | 175 |
Handlebar Width | 780 | 780 | 780 | 780 | 780 | 780 |
Stem Length | 35 | 35 | 35 | 35 | 50 | 50 |
Saddle Width | 155 | 155 | 143 | 143 | 143 | 143 |
Seatpost Length | 100 | 125 | 150 | 170 | 170 | 170 |
Stack (Low BB) | 614 | 613 | 622 | 632 | 641 | 650 |
Stack (High BB) | 610 | 609 | 618 | 627 | 636 | 646 |
Reach (Low BB) | 410 | 430 | 450 | 475 | 500 | 530 |
Reach (High BB) | 415 | 435 | 455 | 480 | 505 | 535 |
Headtube Length | 95 | 100 | 110 | 120 | 130 | 140 |
Headtube Angle (Low BB) | 65 | 65 | 65 | 65 | 65 | 65 |
Headtube Angle (High BB) | 65.5 | 65.5 | 65.5 | 65.5 | 65.5 | 65.5 |
BB Height (Low BB) | 328 | 333 | 333 | 333 | 333 | 333 |
BB Height (High BB) | 335 | 340 | 340 | 340 | 340 | 340 |
BB Drop (Low BB) | 47 | 42 | 42 | 42 | 42 | 42 |
BB Drop (High BB) | 40 | 35 | 35 | 35 | 35 | 35 |
Trail (Low BB) | 126 | 126 | 126 | 126 | 126 | 126 |
Trail (High BB) | 123 | 123 | 123 | 123 | 123 | 123 |
Fork Length (full) | 550 | 550 | 550 | 550 | 550 | 550 |
Fork Rake/Offset | 44 | 44 | 44 | 44 | 44 | 44 |
Front Center | 724 | 746 | 770 | 800 | 829 | 863 |
Chainstay Length | 432 | 432 | 432 | 432 | 442 | 442 |
Wheelbase | 1152 | 1175 | 1200 | 1228 | 1268 | 1302 |
Top-tube Length (horizontal) | 563 | 583 | 605 | 632 | 660 | 692 |
Bike Standover Height | 730 | 734 | 744 | 749 | 757 | 757 |
Seat Tube Length | 385 | 385 | 405 | 425 | 445 | 465 |
Seat Tube Angle (Low BB) | 76 | 76 | 76 | 76 | 76 | 76 |
Seat Tube Angle (High BB) | 76.5 | 76.5 | 76.5 | 76.5 | 76.5 | 76.5 |
Max Seatpost Insertion | 220 | 220 | 240 | 260 | 280 | 300 |
Min Seatpost Insertion | 80 | 80 | 80 | 80 | 80 | 80 |
