CADRU DE ALUMINIUM CU BORSETA PENTRU SCULE
CURSĂ 130 MM, FURCĂ ROCKSHOX RECON GOLD RL ȘI AMORTIZOR SPATE ROCKSHOX DELUXE SELECT
TRANSMISIE SHIMANO DEORE 1X12
Durata de livrare: 24-48 ore
With the upgrade of our well-known F.O.L.D. kinematics, your THRON 6.8 is ready for even more trail fun. We kept the well-liked sensitivity of the F.O.L.D. but changed the positioning of our kinematics within the frame for strong bottom-out resistance. The characteristics are completely progressive which results in a chassis that offers a lot of stability in any terrain. This allows you to handle any trail while the chassis still provides comfort for long laps. Furthermore, the lower standover of the THRON 6.8 gives you more space to play on the trail.
The THRON is made to surf trails. It is made for your inner child, made to have fun and awaken the explorer that you are. The geometry of the THRON makes you feel comfortable and confident in any situation. You are in control whether it's a technical or flow trail, no matter you go up or down. Pure riding fun first. You stay relaxed on long tours and go fast on trails. Smooth running 29" wheels support both riders experienced and beginner.
It's all about the details: The specially developed C.I.S. (Cockpit Integration Solution) design ensures a clean cockpit and constantly seamless shifting and braking. All cables run from the handlebar into the stem and through the headset into the frame. Furthermore, the THRON comes with a tool bag between the top and down tube angle. The tool bag offers space for all your essentials like a multi-tool, tube and a small pump.
Model: Unisex
Tip cadru: Full suspension
Material cadru: Aluminiu
Aplicație: Trail
Diametru roată (inch): 29
Sistem de frânare: Disc-hidraulic
Transmisie: 1x12 viteze
Culori: Gri
Amortizor spate: Rock Shox Deluxe Select, 190/45 mm, hardware: 25 x 8mm, custom tune
Angrenaj: Shimano Deore M6120, 12-speed, 32T
Anvelopă față: Maxxis Dissector, 2.4 Exo, 61-622
Anvelopă spate: Maxxis Rekon 2.4 Exo, 61-622
Butuc față: Novatec D041, 15x110 mm thru axle
Butuc spate: Novatec D462SB, 12x148 mm
Cadru: 7005 hydroformed aluminum, 130 mm F.O.L.D. Gen2 kinematics, 148x12 thru axle, internal cable routing, Post Mount 180 mm
Cuvete: ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated
Frâne: Shimano MT420, 4-piston, hydraulic disc brake
Furcă: Rock Shox Recon Gold RL 29 Boost, DebonAir, 110x15 mm, 42 mm rake, 130mm
Ghidon: Aluminium 35 mm, riserbar 11 mm, 760 mm
Jante: Rodi TRYP25, 25-622
Lanț: Shimano Deore CN-M6100, 12-speed
Manetă schimbator: Shimano Deore M6100, 12-speed
Manete frână: Shimano MT420
Pedale: Nu sunt incluse
Pinioane: Shimano Deore M6100, 12-speed, 11-51T
Pipă: FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
Schimbător pinioane: Shimano Deore M6100, 12-speed
Șa: Selle Italia X3
Tijă șa: Post Moderne dropper post PM-171, 31.6 mm
Greutate: 15.7 kg
S | M | L | XL | ||
---|---|---|---|---|---|
SIZE (MM) | 39 | 42 | 45 | 48 | |
SIZE | 390 | 420 | 450 | 470 | |
HANDLEBAR WIDTH (MM) | 760 | 760 | 760 | 760 | |
STEM LENGTH | 50 | 50 | 50 | 50 | |
CRANKARM LENGTH (MM) | 170 | 170 | 170 | 170 | |
SEAT POST LENGTH | 390 | 440 | 480 | 480 | |
A | SEAT TUBE LENGTH | 390 | 420 | 450 | 530 |
B | EFFECTIVE TOP TUBE | 572 | 605 | 640 | 674 |
C | HEAD TUBE ANGLE (MM) | 66.5 | 66.5 | 66.5 | 66.5 |
D | EFFECTIVE SEAT TUBE ANGLE (MM) | 75 | 75 | 75 | 75 |
E | CHAINSTAY LENGTH | 435 | 435 | 435 | 435 |
F | BOTTOM BRACKET DROP | 35 | 35 | 35 | 35 |
G | HEAD TUBE LENGTH | 100 | 110 | 130 | 160 |
H | FORK CONSTRUCTION HEIGHT | 541 | 541 | 541 | 541 |
I | PRE-RAKED FORK | 46 | 46 | 46 | 46 |
J | WHEELBASE LENGTH | 1139 | 1173 | 1211 | 1253 |
K | STACK | 605 | 615 | 633 | 651 |
L | REACH | 410 | 440 | 470 | 500 |
